Chondroid Syringoma of the Thenar Eminence in a US Veterans Administration (VA) Patient

Muntazim Mukit

Ibrahim Ortanca

Nina Krassilnik

Kalyan Dadireddy

Keywords

thenar eminence

chondroid syringoma

hand mass

hyaline cell-rich chondroid syringoma variant

Veterans Administration

November 2021

ISSN 1937-5719

Index ePlasty 2021;21:ic4

Case Summary

A 56-year-old right-hand-dominant man with a history of hypertension presented with a left thenar eminence cystic mass that started 2 months earlier. The patient denied symptoms, trauma, drainage, or pain but was concerned as he had had a tumor removed from his left forearm previously. The mass was stable in size. On examination, the mass was 1.0 x 0.5 cm. The digits on the patient’s left hand were neurovascularly intact; the patient had full range of motion and normal hand cascade. The differential included schwannoma versus ganglion cyst. The patient underwent operative excision and had an uneventful postoperative course. Pathology showed “acral skin with an encapsulated nodular tumor in the dermis, composed of a few ducts, some adipocytes and sheets of ‘plasmacytoid’ cytoplasm, focally residing in a myxoid stroma. The appearances are consistent with a hyaline (myoepithelial) cell-rich mixed tumor or skin.” The case report was deemed institutional board review exempt.

Questions

1. What is chondroid syringoma?

2. How does chondroid syringoma present?

3. What are its histological features?

4. What are the treatment and prognosis?

Chondroid Syringoma

What is chondroid syringoma?

Chondroid syringomas are mixed tumors of the skin composed of epithelial and mesenchymal elements.¹ Hirsch and Helwig first introduced the term in 1961 since these lesions have both epithelial and stromal elements.²Their criteria for diagnosis were as follows: (1) nests of cuboidal or polygonal cells; (2) intercommunicating tubuloalveolar structures lined with 2 or more rows of cuboidal cells; (3) ductal structures composed of 1 or 2 rows of cuboidal cells; (4) occasional keratinous cysts; and a (5) matrix of varying composition.^2-4 A variant of these lesions has been called hyaline cell-rich chondroid syringoma (HCRCS).⁵ The incidence is said to be 0.01% to 0.098%.⁴

Presentation

How does chondroid syringoma present?

Chondroid syringoma usually presents in the head and neck region.^1,3 The mass is slow-growing, firm, and nontender and may present as a papule, subcutaneous nodule, or a cyst ranging in size from 0.5 to 3.0 cm.^1,3 The lesions are typically adherent to the skin and usually occur in adults older than 35 years.⁶ The male to female ratio is reported to range from 2:1 to 5:1.^1,3,6 In the literature, chondroid syringomas have been reported in the hand but its occurrence is still rare. One report states that there have been only 22 patients who have chondroid syringoma in the hand.¹ Another report found that the HCRCS variant has a predilection for the extremities, consistent with our patient’s presentation.⁵ Clinically, these lesions may be confused with sebaceous cysts, dermoid cysts, or neurofibromas.⁷

Histological Features

What are its histological features?

On histology, these tumors appear similar to benign salivary gland mixed tumors.¹ The cells have eosinophilic hyaline stroma and plasmacytoid features.⁵ The stroma may be myxoid, chondroid, fibrous, adipocytic, or osseous.¹ Headington⁸ categorized chondroid syringomas into 2 types, apocrine and eccrine. The eccrine type consists of small, round tubules that are evenly spaced in a myxoid-chondroid matrix, while the apocrine type consists of irregularly branching tubules lined by thicker epitheliaum.¹The HCRCS variant consists of plasmacytoid cells with hyaline cytoplasm in a myxochondroid to hyaline stroma and stains positive for cytokeratin, vimentin, and S100, with inconsistent expression of myoepithelial differentiation markers such as actin and calponin.⁵Our patient’s mass had a similar histological appearance and immunohistochemical profile, staining positively for cytokeratin and S100 and focally for calponin. (Figure 1, Figure 2, Figure 3, Figure 4)

Figure 1 Mukit VA — **Figure 1.** Low-power image showing a well-circumscribed, encapsulated tumor in subcutis (H&E, original magnification × 2).

Figure 2 Mukit VA — **Figure 2.** Tumor is composed of epithelioid cells with abundant eosinophilic cytoplasm, representing myoepithelial cells. Scattered are a few ducts lined by cuboidal epithelial cells. The stroma is hyalinized (H&E, original magnification × 10).

Figure 3 Mukit VA — **Figure 3.** Broad-spectrum cytokeratin stains both epithelial and myoepithe- lial cells. Epithelial cells and staining ducts are more crisp (IHC for AE1/3, original magnification × 10).

Figure 4 Mukit VA — **Figure 4.** SMA immunohistostaining highlights the myoepithelial cells around ducts.

Treatments and Prognosis

What are the treatment and prognosis?

The treatment of chondroid syringoma is excision. Excision is also diagnostic.³ Recurrence happens secondary to incomplete excision.^1,6 Including some normal tissue with excision can help guarantee complete removal.⁴Most lesions are benign. Malignant chondroid syringomas are thought to arise de novo and not from existing benign lesions.³ Malignant lesions are usually larger, more commonly seen in women, and located on the extremities or the trunk, with a 1:2 male to female ratio and average age of diagnosis of 48 years.^1,3,6 Malignant lesions may invade locally and/or metastasize to lymph nodes, bone, or lung.⁶ Some reports state that cytologic atypia, tumor necrosis, several mitosis, poorly differentiated chondroid elements, and an excessive mucoid matrix are suggestive of malignancy, but other reports have found that lesions may not have any of these features and still be malignant.^3,6 (Figure 5)

Figure 5 Mukit VA — **Figure 5.** Postoperative day 9 anteroposterior photograph of the left hand showing a well-healed incision of thenar eminence.

Summary

Chondroid syringoma is a benign mixed tumor of the skin.¹The HCRCS variant consists of plasmacytoid cells in a myxochondroid/hyaline stroma and stains for cytokeratin, S100, vimentin, and sometimes actin and calponin.⁵The HCRCS variant appears on extremities. Surgical excision is diagnostic and curative. Recurrence occurs due to incomplete excision.^1,6

Acknowledgments

Authors: Muntazim Mukit, MD, Ibrahim Ortanca, MD, Nina Krassilnik, MD, and Kalyan Dadireddy, MD

Affiliations: Memphis Veterans Administration Medical Center (VAMC), Memphis, TN; University of Tennessee Health Science Center (UTHSC), Memphis, TN

Correspondance: Muntazim Mukit mmukit@uthsc.edu

Disclosures: None of the authors have any conflicts of interest to disclose.

References

1. Borman H, Deniz LM, Ertas NM, et al. Chondroid syringoma of the hand. Scand J Plast Reconstr Surg Hand Surg. 2009;43(5):291-3.

2. Hirsch P, Helwing EB. Chondroiod syringoma mixed tumor of skin, salivary gland type. Arch Dermatol. 1961;84:835-47.

3. Abi-Falah R, Gebre-Giorgis A, Rhodes J, et al. Chondroid syringoma: a case report. ePlasty. 2015;15:ic30.

4. Sulochana S, Manoharan M. Anitha. Chondroid syringoma—an unusual presentation. J Clin Diagn Res. 2014;8(7), FD13-4.

5. Reis-Filho JS, Silva P, Milanezi F, Lopes JM. Hyaline cell-rich chondroid syringoma: case report and review of the literature. Pathol Res Pract. 2002;198(11):755-64.

6. Lowe J, Ly JQ, Lusk JD, et al. Benign chondroid syringoma. Appl Radiol. 2009:38-9, Available from: https://appliedradiology.com/articles/benign-chondroid-syringoma Accessed March 9th 2020.

7. Kumar A, Sinha A, Kumar B, et al. Chondroid syringoma. Singapore Med J. 2008;49(2):e33.

8. Headington JT. Mixed tumors of skin: eccrine and apocrine types. Arch Dermatol. 1961;84:989-96.
